รายละเอียดสินค้า:
|
| ความหนาของการเคลือบสี: | ด้านบน: 10 ~ 25 μmกลับ: 5 ~ 15 μm | เคลือบสังกะสี: | 40 ~ 275 g/m² |
|---|---|---|---|
| ความหนา: | 0.12 มม. ~ 1.5 มม. | ความกว้าง: | 600 มม. ~ 1250 มม. |
| น้ำหนักคอยล์: | 3 ~ 10 ตัน | สี: | รหัสสี RAL หรือสีที่กำหนดเอง |
| พื้นผิวเสร็จสิ้น: | เคลือบมัน, เคลือบ, นูน | ขั้นต่ำ: | 5 ตันเราสามารถยอมรับคำสั่งซื้อตัวอย่างได้ |
![]()
![]()
| Specification | |
| Product Name | Pre-painted Galvanized Steel Coil (PPGI) |
| Thickness | 0.12mm ~ 1.5mm |
| Paint Coating Thickness | Top: 10 ~ 25 μm Back: 5 ~ 15 μm |
| Width | 600mm ~ 1250mm |
| Zinc Coating | 40 ~ 275 g/m² |
| Coil Weight | 3~10 tons |
Coating Properties |
|
| Types | PE (Polyester) SMP (Silicone Modified Polyester) PVDF (Polyvinylidene Fluoride) HDP (High Durable Polyester) |
| Colors | RAL color code or customized color |
| Surface Finish | Glossy, Matte, Embossed |
| Other | |
| MOQ | 5 ton, we can accept sample order |
| Payment Term | 30%T/T Advance + 70% Balance |
| Export Packing | Standard seaworthy export packing with waterproof paper + edge protector + galvanized steel wrapping + pallet |
| Delivery Time | Fast delivery in 7 days or up to order quantity |
![]()
![]()
![]()
![]()
![]()
